Timco C2 Clamp-Fix Multi-Purpose Premium Screws – Yellow 5.0 x 100 – TX – Double Countersunk- Box of 100 – 50100C2C

£7.04 £5.87 Ex VAT

A premium multi-material screw featuring the award winning C2 twin-cut technology. The dual angle partial thread and high torque TX drive ensures maximum clamping strength on every fixing. Designed to prevent the timber from ‘jacking’ apart when fastening timber to timber. Ideal for applications such as timber studwork, panelling, roof and decking framework.

• Precision TX drive recess to prevent ‘cam-out’, giving a precise and positive drive control on every screw
• Ribs under head for improved countersinking and to give a smooth and flush finish, also prevents splitting and material damage
• Coated with a high-molecular polymer lubricant that reduces the insertion torque by up to 52% and increases rust protection up to 20 times longer than a standard zinc plating
• Dual angle thread for ultimate performance and exceptionally high pull-out resistance
• Patented twin cut technology for rapid “pick-up” and reduces timber splitting
• Partially threaded from 40mm

6400 in stock

SKU: 50100C2C Category:

Description

  • Max. CFT (mm) 40
    Thread Ø (mm) 5
    Shank Type Helix
    CE Standard BS EN 14592:2008
    Head Ø (mm) 9.7
    Finish Zinc & Yellow
    Material Carbon Steel
    Recess Type TX Drive
    Point Type Twin-Cut
    Gauge 10
    Pack Type Box
    Pack Qty 100
    Inner Thread Ø d1 (mm) 2.95
    L (mm) 100
    Thread Type 40° Single
    Driver Bit Size TX25
    Corrosion Rating (1-5) 2 – Occasionally damp/wet, rural and sheltered areas
    Substrates Hardwood, Softwood, Chipboard, MDF, Plastic, Thin Sheet Metal
    Lubrication Wax
    Size (imp.) 10 x 4
    Thread L (mm) 60
    Size (mm) 5.0 x 100
    L (inch) 10 x 4
    Feature 3 Coated with a high-molecular polymer lubricant that reduces the insertion torque by up to 52% and increases rust protection up to 20 times longer than a standard zinc plating
    Feature 6 Partially threaded from 40mm
    Feature 2 Ribs under head for improved countersinking and to give a smooth and flush finish, also prevents splitting and material damage
    Brand TIMCO
    Feature 1 Precision TX drive recess to prevent ‘cam-out’, giving a precise and positive drive control on every screw
    Feature 5 Patented twin cut technology for rapid “pick-up” and reduces timber splitting
    Thread Coverage Partially Threaded
    Pack Dimensions L x W x H (mm) 140 x 94 x 60
    Pack Weight (kg) 0.84
    Feature 4 Dual angle thread for ultimate performance and exceptionally high pull-out resistance
    Head Type Double Countersunk with Ribs
    Included Items TX25 25mm Power Bits (Qty 1)

Additional information

Weight 0.84 kg
